Condor Stainless Steel Solid
EX700-SS-S-07-NC
Condor Stainless Steel Solid
EX700-SS-S-07-NC
Bottom Conduit Connection (T1): 3/4" (2)
Side Conduit Connections (T2): 3/4" (2)
Cover Style: Solid
Gasket: Fluoroelastomer gasket
Window Diameter: N/A
Approvals: UL (US-C), CSA (C-US), ATEX, IECEx
Enclosure Rating: UL & CSA: Type 4X/IP68; ATEX & IECEx: IP68
Color: N/A
Temperature Range: °F (°C): -67 to 185 (-55 to 85)
Weight: lbs (kg): 20.6 (9.3)
Outside Dimensions: 6.42" x 7.97" x 8.45" (163 x 202 x 214 mm) (W x H x D)
Instrument Tag Loop: Cast-in loop for securing stainless steel tag
Tamper-Proof Seal Provision: Base and cover can be secured with wire and lead seal
Ground Screws: Internal and external
Nameplate Galleries: Number: Two; Securing Method: Two drilled and tapped holes
Nameplate Dimensions: 2.61" x 1.36" (66 x 35 mm)
Nameplate Screw: #2-56 x 3.2 mm Torx/Torx Plus/Star thin head machine screw. Material: 316 Stainless Steel. (Not supplied for second nameplate gallery)
Nameplate Material: 316 stainless steel plate, 26 gauge (0.475 mm thick)
Data Sheet
Manual
CAD Drawings
SKU: EX700-SS-S-07-NC
Stock: 2
Price (1-49 pieces): $1,531.75
Substantial quantity discounts available; contact factory for details.
Cover
Solid cover
Material
ASTM A743 CF8M investment-cast
316 stainless steel
Conduits
Bottom Conduit Connections (T1): 3/4" (2)
Side Conduit Connections (T2): 3/4" (2)
Dimensions
CAD Drawings
To download 2D CAD drawings please visit our CAD Drawings page. 3D CAD Drawings are available upon request. Please visit our CAD Drawings page for request form and instructions.
